| Transmission Standards | |
| DVB-S2/S, DVB-T/T2,DVB-C | |
| Satellite Input/Demodulation | |
| Connector | F Type |
| Input Frequency | 950 to 2150 MHz |
| Signal Input Level | 0~-80 dBm |
| Band Switch Control | 22 kHz |
| LNB Supply | 13V/18V.IMax 350mA |
| Demodulation Type | QPSK , 8PSK, 16APSK |
| Symbol rate | 2<Rs <45 Mband (SCPC/MCPC) |
| DVB-T/T2 Input/Demodulation | |
| Connector Type | F Type |
| Input Frequency | 48 to 862 MHz |
| Signal Input Level | 0 ~ -80dbm |
| Demodulation Type | 16QAM,64QAM,256QAM(DVBT2) |
| DVB-C Input/Demodulation | |
| Connector Type | F Type |
| Input Frequency | 48 to 862 MHz |
| Signal Input Level | 0 ~ -67dBm |
| Demodulation Type | 64QAM,256QAM |
| LCD Features | |
| LCD Type | TFT Transmissive |
| Number of Dots | 320 (RGB) x240 |
| LCD screen | 2.4" |
| Data Service Port | |
| Connector | USB |
| Data protocol | USB2.0 interface |
| File Manage ment System | NTFS,FAT32 |
| File Format | wma,mp3,avi,jpg,jpeg,bmp etc |
| Power Supply | |
| Li-lon Battery | 7.4V/2600mAh |
| Adapter |
Output: DC12V/1A Input: 100 ~ 240VAC, 50/60Hz |
| Power Consumption | Max. 10W |
| Physical Characerstics | |
| Size (W x D x H) | 17×8×4 (cm3) |
| Net Weight | about 0.7kg |
